Sand Pump

Sand Pump for Dredging Horizontal Wear Resistance Centrifugal

Max.Head: 30-50m
Driving Type: Motor
Impeller Number: Single-Stage Pump
Working Pressure: High Pressure Pump
If you are interesting at Sand Pump for Dredging Horizontal Wear Resistance Centrifugal,you can contact us with the inquiry button.
INQUIRY WhatsApp

Description of Sand Pump for Dredging Horizontal Wear Resistance Centrifugal

Basic Info.

Model NO.

450WN

Influent Type of Impeller

Single Suction Pump

Position of Pump Shaft

Horizontal Pump

Pump Casing Combined

Horizontal Split Pumps

Mounting Height

Suction Centrifugal

Impeller

Closed

Usage

Pump, Pumps, Condensate Pump, Ash Pumps, Circulating Pump

Speed

550-700

Inlet Dia

350

Outlet Dia

200

Transport Package

Export Standard Packing and Shipped by Sea

Specification

1000*1000mm

Main Features

1.The whole construction is suitable for dredging ship.
2.Easy disassembly and installation,convenient maintenance.
3.Dredging performance is excellent.
4.Strong through-put capacity,wide application.
5.The curve of performance decreases sharply.
6.Excellent anti-wear performance,long service of wet parts.
7.A little hydraulic loss,high efficiency,low power consumption.
8.Reliable shaft sealing without leakage.
