Truck Mounted Water Well Drilling rig

300m deep well truck mounted water well drilling rig for sale

Max drill depth：300m
Hole diameter：105-325mm
Pipe diameter：76-89mm
Truck chassis：6*4
If you are interesting at 300m deep well truck mounted water well drilling rig for sale,you can contact us with the inquiry button.
INQUIRY WhatsApp

Description of 300m deep well truck mounted water well drilling rig for sale

300m deep well truck mounted water well Drilling Rig parameters:

300m deep well truck mounted water <a href=https://www.gzpearldrill.com/en/Water-well-drilling-rigs.html target='_blank'>well drilling rig</a> for sale

The hole diameter(mm)：140-305

Drilling depth(m)：300m

Equipped capacitor(KW)：75Kw or truck engine direct connection

Drill pipe diameter(mm)：76/89

Hoisting force of winch(T)：1.5T

The penetration efficiency(m/h)：15-35

One-tine advance length(m)：6.6

Rig lifting force(T)：17

Swing torque(N.m)：4500-6000

Swing speed(rpm)：40-70

Using air pressure(MAP)：1.7-3.0

Air consumption(m³/min)：17-31

Air compressor (optional)

Discharge pressure(Bar)：25

Engine displacement(m/min)：31

Other Optional Parts：Foam pump

14.5m3/min

Mud Pump： BW250/450

Truck： Dong Feng/HOWO

Multifunctional generator： Can generate electricity and can be welded (convenient casing)

300m deep well truck mounted water well drilling rig feature:

1. The PDT series multi-functional vehicle-mounted water well rock drill is a new, efficient and multi-functional fully hydraulic rock drill. It is mainly used for drilling water wells, monitoring wells, geothermal adjustment holes, hydropower cofferdam grouting holes, and dam anti-seepage grouting. holes, foundation reinforcement grouting holes, open pit mining, anchoring, national protection projects and various deep hole drilling processes.

2. The drilling rig is equipped with a high-power hydraulic motor, hydraulic boom, DTt hammer drilling machine, and large drift mud pump, which can realize mud drilling.

3. The mud pump and air compressor are both on the same car chassis, which is lightweight and efficient, and its standard performance is better than other types of drilling rigs. According to customer requirements, it can be equipped with neutral diesel engine.
